Caraxes

Caraxes is the reliability, chaos, and capacity evidence harness for CamusDB. It lives in the camusdb-caraxes repository. It builds a Docker cluster from a declarative YAML spec, drives SQL load through CamusDB.Workload, injects process, network, disk, and topology faults, and turns the collected artifacts into a PASS or FAIL verdict.

Use Caraxes when you want evidence about the behavior of a build. A passing run does not prove CamusDB correct for every possible history. It says that the specific build, cluster shape, workload, faults, and checks in the scenario survived the measured window and left artifacts that explain the result.

Caraxes has been used to catch, fix, and prevent user-facing failures in these areas:

• Atomicity regressions during contended bank transfers, where the conserved balance changed after a run.
• Scan visibility defects that post-run reconciliation could not see, because COUNT(*) was short only while writes were in flight.
• Crash, re-election, rejoin, and leader-transfer bugs around kill, pause, partition, stop, and zone-loss scenarios.
• Full-disk and slow-device behavior, including write admission when a node is out of space and recovery when a durable write path stalls.
• Placement, range-split, and leader-balancer regressions that only show up when every partition or every failure zone carries work.
• Measurement false positives caused by host disk regime changes, host load, client saturation, moving placement, or comparing runs from different builds or durability settings.
• Lost diagnostic evidence after teardown, by preserving node logs and crash dumps before containers and volumes are removed.

The harness lives in its own repository, beside a checkout of CamusDB. It builds the node image from docker/Dockerfile in the CamusDB checkout, so a run tests the code on your disk.

Requirements

• .NET 10 SDK
• Docker with docker compose
• A CamusDB checkout, ~/camusdb by default

Run every command below from the root of the Caraxes repository.

Cluster lifecycle

Four commands manage a cluster without a workload:

# build the image, generate artifacts, start the fleet, wait until every node is ready
dotnet run --project Caraxes -- up --spec scenarios/cluster-3.yml

# per-node health plus the cluster's partition placement table
dotnet run --project Caraxes -- status --spec scenarios/cluster-3.yml

# one node's container logs
dotnet run --project Caraxes -- logs --spec scenarios/cluster-3.yml --node camus2

# stop the cluster and remove its containers, network, and volumes
dotnet run --project Caraxes -- down --spec scenarios/cluster-3.yml

up builds the image, writes one config.yml for each node and one compose.yml under runs/<cluster>/, starts the fleet, and polls GET /v1/cluster/health until every node is ready. Pass --skip-build to reuse the existing image. Pass --ready-timeout <seconds> to change the default 180-second readiness deadline.

down removes data volumes unless you pass --keep-volumes. The run directory is disposable output; the spec is the source of truth. down recreates the compose file and still works after you delete runs/.

The nodes are named camus1 through camusN. Node i publishes REST on host port 15095 + i - 1 and gRPC on 16095 + i - 1, so a Caraxes cluster can run beside a local development server on ports 5095 and 5096.

Cluster spec

A cluster spec is YAML. Only name is required.

name: rf3-baseline
nodes: 3
partitions: 3
replication_factor: 3
placement_rebalancer: true
leader_balancer: true
locking: optimistic
isolation: read_committed
diagnostics: true

Key	Default	Meaning
name	(required)	Lowercase [a-z0-9-] identifier. Names containers, volumes, the compose project, and the derived image tag.
nodes	3	Node count.
partitions	3	Initial cluster partitions.
replication_factor	3	Per-partition replica-set size. 0 keeps full replication, where every node hosts every partition.
placement_rebalancer	true	Repair under-replication, trim over-replication, and smooth skew on join or leave.
leader_balancer	true	Spread partition leadership using load reports.
zones	[]	One failure-zone label per node, parallel to the node list. Empty means zone-unaware placement.
locking	optimistic	Maps to CamusDB default_transaction_locking.
isolation	read_committed	Maps to CamusDB default_isolation_level.
read_validation	(engine default)	Optional default_read_validation, usually swept when testing pessimistic transaction behavior.
key_range_sharding	false	Maps to CamusDB key_range_sharding.
distributed_query_execution	false	Maps to CamusDB distributed_query_execution. See Distributed Queries.
max_query_parallelism	1	Maps to CamusDB max_query_parallelism.
diagnostics	true	Turns on OpenTelemetry and the Prometheus /metrics endpoint on every node.
subnet	10.101.0	First three octets of the cluster's /24 bridge network.
first_ip	2	Last octet of node 1. Node i gets first_ip + i - 1.
base_rest_port	15095	Host port of node 1's REST API.
base_grpc_port	16095	Host port of node 1's gRPC API.
base_raft_port	7070	Raft port of node 1. Node i advertises base_raft_port + 2 * (i - 1). Not published to the host.
spare_certs	5	Extra certificate SAN entries, so a node added later is covered without regenerating certificates.
data_tmpfs_mb	0	When above zero, each node's /data is a size-capped tmpfs instead of a named volume. Required by fill-disk.
memory_limit_mb	0	Optional container memory limit for each node, useful for OOM and memory-posture soaks.
gc_heap_hard_limit_mb	0	Optional managed-heap hard limit. Use with memory_limit_mb, especially when data_tmpfs_mb charges data pages to the same cgroup.
camusdb_repo	~/camusdb	Path of the CamusDB checkout that supplies the Dockerfile, certificate script, and build context.
image	(derived)	Image tag. Empty derives caraxes/camusdb:{name}.
kahuna	{}	Raw passthrough into the generated config's kahuna: section, for engine knobs the spec does not model.
log_levels	{}	Per-category log-level overrides for diagnostic runs, for example election or leader-balancer investigations.

Caraxes validates the spec before anything starts. Invalid names, zones, subnet forms, ports, locking modes, isolation levels, and impossible memory or disk settings fail immediately with exit code 2.

Running a scenario

A scenario is one file with a cluster: block and a workload: block. It can also include a nemesis: fault schedule, checks:, and run-level controls.

dotnet run --project Caraxes -- run --scenario scenarios/smoke-optimistic.yml

The verb run performs the whole cycle:

1. Publish CamusDB.Workload from the CamusDB checkout.
2. Bring the cluster up and wait until every node is ready.
3. Seed the dataset with CamusDB.Workload init.
4. Wait for partition leadership to settle, according to settle_seconds.
5. Drive the measured run, with the nemesis schedule in parallel when there is one.
6. Collect workload artifacts, node metrics, cluster facts, logs, crash dumps, and host evidence.
7. Correlate faults, write the verdict, and tear the cluster down unless teardown: false.

The command exits 0 on PASS, 1 on FAIL, and 2 for an invalid spec, scenario, or matrix file. Your CI can gate on it directly.

The workload runs in a one-shot container attached to the cluster's Docker network. It reaches every node over TLS using the in-cluster DNS names, without changing trust on the host.

name: smoke-optimistic
cluster:
  name: smoke-opt
  nodes: 3
  partitions: 3
  replication_factor: 3
  locking: optimistic
  isolation: read_committed
workload:
  database: caraxes
  rows: 20000
  mode: open
  target_ops: 400
  workers: 32
  duration: 60s
  warmup: 15s
  read_percent: 60
  write_percent: 40
teardown: true

Workload block

The keys of the workload: block map onto CamusDB.Workload flags. Defaults are lighter than the standalone workload utility because chaos scenarios run many workloads and care about behavior under fault, not just peak throughput.

Key	Default	Meaning
kind	accounts	accounts for shard-disjoint read-modify-write, bank for conserved-balance transfers, fanout for cross-table bank transfers that load every partition.
database	caraxes	Database the scenario seeds and drives. init creates it when it is absent.
seed	1847	Dataset and workload seed.
rows	100000	Seeded row count.
tables	1	Number of tables to spread rows over. fanout requires at least 2.
payload_bytes	256	Payload size per row.
batch	500	Rows per seeding transaction.
mode	open	open for a fixed arrival rate, closed for saturation.
target_ops	500	Open-loop submitted operations per second.
workers	32	Concurrent workers.
read_percent / write_percent	60 / 40	Operation mix. The two must add up to 100.
writes_per_transaction	1	Writes per write transaction.
duration	60s	Measured window.
warmup	15s	Unmeasured warmup.
drain	10s	Drain period after the measured window.
connections	8	Client connections.
max_in_flight	4096	Concurrency ceiling.
locking	(inherits)	Empty inherits the cluster's locking.
isolation	(inherits)	Empty inherits the cluster's isolation.
routing_mode	(driver default)	Optional learned statement routing mode: off, learned, or auto.
connection_options	(empty)	Extra client connection-string pairs for the measured run.
gateway	endpoint pool	Send all requests through one node, or leave empty for the normal round-robin node pool.
no_auto_prepare	false	Disables automatic prepared statements.
request_timeout	0	Per-request timeout in seconds. 0 keeps the client default.
expect_faults	true	Treats conflicts and open-loop pacing shortfalls as expected chaos-run noise instead of invalidating the run.
reconcile_timeout	0	Extra time for post-run aggregate reconciliation on a settling cluster. 0 keeps the workload default.
scan_probe_interval	(off)	Run in-window COUNT(*) probes on every gateway, for example 5s.
scan_probe_timeout	0	Per-probe request timeout in seconds. 0 keeps the workload default.
node_metrics	true	Collect node-metrics.csv and bottleneck-report evidence from every node. Requires diagnostics.
metrics_interval	5s	Scrape interval for node metrics.
cluster_facts	true	Write cluster-facts.json with build, config, readiness, durability, and placement facts from the nodes.

A duration accepts forms such as 15s, 1m, 250ms, and 1h. A bare number means seconds.

Workloads and what they detect

accounts is the baseline load. It performs shard-disjoint read-modify-write operations, which makes it useful for smoke tests, throughput ceilings, and general fault recovery without intentionally creating write/write contention.

bank uses transfers between two rows across the whole key space. Every transfer must preserve SUM(balance) and commit atomically. Caraxes checks that sum after the run and never waives it. Conflicts under fault can be expected; a changed balance is a correctness failure.

fanout keeps the bank invariant but spreads the dataset over many tables and moves each transfer between two different tables. That makes every partition carry writes and gives range-split, placement, failover, and leader-balancer logic meaningful work to move around.

The scan probe is a live visibility check. With scan_probe_interval enabled, the workload runs SELECT COUNT(*) on every gateway during the measured window. This catches short scans under concurrent writes that a quiet post-run reconciliation can miss.

Fault injection

A nemesis: block drives faults at the same time as the workload. Caraxes times every event from the start of the measured run, so fault windows align with the per-second series in intervals.csv.

nemesis:
  seed: 7
  events:
    - { at: 20s, fault: kill, target: random, duration: 20s }

Fault kinds

Fault	What it does	Heals by
kill	SIGKILL the node process. Exercises crash recovery and re-election.	Restarting the container.
stop	Graceful stop: SIGTERM, then SIGKILL after Docker's grace period.	Restarting the container.
pause	Freeze the process with SIGSTOP. TCP connections stay open, so suspicion timeouts are exercised.	SIGCONT.
partition	Isolate the node from every peer with iptables DROP rules in both directions.	Flushing the node's filter table.
slow	Add one-way latency with tc qdisc netem. Set delay_ms, default 100.	Removing the qdisc.
loss	Add packet loss with tc qdisc netem. Set loss_percent, default 10.	Removing the qdisc.
fill-disk	Write a filler file into /data until the mount returns ENOSPC.	Deleting the filler.
slow-disk	Cap a node's block I/O with cgroup v2 io.max, modeling a slow or paused durable device.	Removing the throttle.
remove-node	Drain the node through POST /v1/cluster/leave, then stop the container.	Never. This is a one-way scale-down.

Set heal: false on an event to hold it open for the rest of the run. A kill without healing becomes a crash without repair. A partition without healing leaves the cluster to continue without the isolated node.

Targets can be a node name such as camus2, random, or zone:<name>. random is seeded and reproducible. A zone target expands to every node in that failure zone, so a zone kill takes the whole zone down together.

A seeded random: soak is the alternative to an explicit events: timeline:

nemesis:
  seed: 42
  random:
    faults: [kill, pause, partition, slow, slow-disk]
    min_interval: 10s
    max_interval: 18s
    duration: 12s

Disk faults

fill-disk needs a size cap, so the cluster must set data_tmpfs_mb. Each node's /data becomes a RAM-backed, size-capped tmpfs that the fault can exhaust. The full node must refuse writes cleanly with CADB0536 (InsufficientDiskSpace) and admit writes again after the filler is deleted, without a restart. Because tmpfs disappears on restart, this tests disk-pressure behavior, not durability.

slow-disk targets the durable path instead. It uses cgroup v2 io.max to cap the block device behind Docker's named volumes, while the node process, network, and peers remain healthy. The default write_bps: 4096 is effectively a paused device for write-heavy workloads; a few MiB per second models a merely slow disk. write_iops, read_bps, and device: "MAJ:MIN" can tune or override the cap. The fault refuses tmpfs-backed data because those writes do not reach the block device.

nemesis:
  events:
    - { at: 4m, fault: slow-disk, target: camus1, duration: 30s }
    - { at: 7m, fault: slow-disk, target: camus2, duration: 60s, write_bps: 2097152 }

The slow-disk implementation avoids creating or removing containers while the throttle is active. Container removal can force overlay writeback through the throttled device and stall Docker itself, which would make the test measure the host rather than CamusDB.

Verdict

A scenario passes when the workload accepted the run, reconciliation held, internal errors were explained by the injected fault context, and every configured resilience check passed.

For a run with faults, Caraxes correlates the nemesis timeline.jsonl with the workload's per-second intervals.csv. Each fault window yields the peak error rate, whether the workload continued to complete operations, and the recovery time from heal until the error rate returns near zero.

checks:
  max_recovery_seconds: 45
  require_recovery: true
  require_progress_under_fault: true

Key	Default	Fails the run when
max_recovery_seconds	45	A healed fault took longer than this to recover.
require_recovery	true	A healed fault never recovered before the run ended.
require_progress_under_fault	true	A fault window completed zero operations, meaning a total outage.

A second counts as recovered at an error rate of 1 percent or below. Caraxes writes the correlation to analysis.md and scenario.json.

# Fault analysis - bank-kill

- Baseline (clean seconds): error rate 0.00 %, write p99 1,382.0 ms
- In-fault: error rate 40.45 %, write p99 392.9 ms (0.3x baseline)
- Max recovery time: 5.5 s; all healed faults recovered: yes

| fault | healed | window (s) | peak error | failed | progressed | recovery (s) |
|---|---|---|---|---|---|---|
| kill/camus2 | yes | 20.3 | 100 % | 4,074 | yes | 5.5 |

Measurement evidence

Caraxes records more than a single throughput number because cluster reliability and capacity results are easy to misread without context.

cluster-facts.json records what each node was actually running: build and assembly versions, resolved configuration, readiness, durability-relevant settings, and table or range placement. This prevents comparing two runs that look similar but were taken against different builds or storage settings.

node-metrics.csv and bottleneck-report.md show per-node work distribution, commit path, batch density, and backlog growth. They make it visible when a flat cluster-wide rate hides one write leader carrying all durable work.

client-resources.json records the load generator's own CPU, memory, and headroom, so a saturated client does not get mistaken for a server limit.

host-io.csv and host-load notes capture the benchmark machine's behavior. This matters for sustained storage tests where the host device can change regime mid-run and make two identical CamusDB builds appear different.

precondition_device_gb writes fsynced ballast during warmup and records precondition.json, so a measured window can start after the host device has entered its steady write regime. Tmpfs, unpreconditioned NVMe, and preconditioned NVMe runs are separate denominators and should be compared only within the same posture.

settle_seconds waits after seeding for partition leadership to resolve before the measured window opens. If leadership never settles in time, the run continues with a note instead of silently charging the benchmark for an election it did not cause.

drain_observation_seconds keeps scraping node metrics after the workload ends, so deferred work can be watched draining to idle without affecting the measured numbers.

capture_node_logs defaults to true and writes node-log-camusN.txt before teardown. Crash dumps are written under runs/clusters/<name>/dumps/camusN/, outside /data, so they survive both tmpfs data mounts and down -v.

Matrix sweeps

A matrix runs a cartesian product of scenario settings and writes a report across the cells.

dotnet run --project Caraxes -- matrix --matrix scenarios/matrix-resilience.yml

A matrix file holds a base cluster: block, workload: block, and checks: block, plus axes:. The cells run one after another through the ordinary scenario path. Each cell gets its own cluster name, containers, and volumes.

axes:
  locking: [optimistic, pessimistic]
  nemesis:
    - name: none
    - name: kill
      seed: 7
      events:
        - { at: 20s, fault: kill, target: random, duration: 20s }

The sweep writes matrix-report.md and matrix.json. They align the verdict, maximum recovery time, latency growth, and first failure note for every cell. The command exits nonzero if any cell failed.

Leader-balance test

This test targets Raft leader balancing directly and uses no workload:

dotnet run --project Caraxes -- leader-balance --spec scenarios/leader-balance.yml

It measures partition leadership through GET /v1/cluster/placement, kills the node with the most leaders, waits for election, restarts that node, and watches the leader balancer move leadership back. The test passes when the rejoined node regains at least half of its fair share and the final spread is near even.

The test writes leader-balance.md and leaders.jsonl with one entry per poll.

Artifacts

Everything a run produces lands under runs/. That output is disposable, but it is the evidence behind the verdict.

Path	Holds
runs/<cluster>/	Generated compose.yml and one config/camusN.yml per node for a cluster started from a bare spec.
runs/clusters/<cluster>/	Generated cluster files for the cluster embedded in a scenario.
runs/clusters/<cluster>/dumps/camusN/	Runtime crash dumps for each node, preserved outside /data.
runs/scenarios/<name>/scenario.json	Run manifest: settings, CamusDB commit, exit codes, verdict, notes, and fault analysis.
runs/scenarios/<name>/analysis.md	Human-readable fault correlation.
runs/scenarios/<name>/timeline.jsonl	One line per injection, heal, error, and note, with UTC timestamp and nemesis offset.
runs/scenarios/<name>/host-io.csv	Host device I/O samples for the run, when available.
runs/scenarios/<name>/precondition.json	Device preconditioning record, when enabled.
runs/scenarios/<name>/artifacts/run/	Workload artifacts such as summary.json, summary.md, intervals.csv, errors.json, reconciliation.json, manifest.json, and run-meta.json.
runs/scenarios/<name>/artifacts/run/cluster-facts.json	Build, config, readiness, durability, and placement facts from the nodes.
runs/scenarios/<name>/artifacts/run/node-metrics.csv	Per-node metric time series.
runs/scenarios/<name>/artifacts/run/bottleneck-report.md	Bottleneck and work-distribution report derived from node metrics.
runs/scenarios/<name>/artifacts/run/client-resources.json	Load-generator resource evidence.
runs/scenarios/<name>/artifacts/run/scan-probe.csv	In-window scan-probe observations, when enabled.
runs/scenarios/<name>/artifacts/run/node-log-camusN.txt	Captured node logs, when capture_node_logs is enabled.
runs/matrix/<name>/	matrix-report.md, matrix.json, and one cell directory per combination.
runs/leader-balance/<cluster>/	leader-balance.md and leaders.jsonl.

scenario.json records the short hash of the CamusDB checkout that Caraxes built. You can trace a verdict back to the code it judged.

Exit codes

Code	Meaning
0	PASS.
1	FAIL, or the harness itself errored.
2	Spec, scenario, or matrix file was invalid or unreadable.
130	Interrupted with Ctrl-C.

Bundled scenarios

The repository includes both small smoke scenarios and longer investigative scenarios. Representative files:

File or family	Tests
cluster-3.yml, cluster-5.yml, cluster-zones.yml	Reusable cluster specs for RF=3, larger clusters, and zone-aware placement.
smoke-optimistic.yml, smoke-pessimistic.yml	Fault-free end-to-end baselines.
kill-follower.yml, partition-and-slow.yml, zone-failure.yml, soak-random.yml	Process, network, zone, and random-chaos recovery.
disk-full.yml, bank-slow-disk-pause-nvme.yml	Full-disk admission/recovery and slow durable-device behavior.
bank-kill.yml, bank-optimistic-*, bank-pessimistic-*, bank-soak-*	Bank invariant under kills, lock modes, and long soaks.
fanout-failover.yml, fanout-gate.yml, split-preflight.yml, split-optimistic-45m.yml, bank-optimistic-split-45m.yml	Many-table placement, failover, and range-split behavior.
capacity-baseline.yml, bank-cap-*, onepart-*, tables-scale-*	Capacity ceilings and partition/table scaling.
p3c-*, bank-rebase-*routing*, wal-*, fsync-gate-*	Performance comparison, WAL/fsync, routing, and storage-path investigations.
leader-balance.yml, leader-selfmove.yml, leader-transfer-probe.yml, leaders-*	Leader-balancer and leader-transfer behavior.
matrix-resilience.yml, matrix-concurrency-sweep*.yml	Cross-product sweeps of configuration, workload, and fault settings.
log-capture-smoke.yml, placement-probe.yml, mem-diagnostic.yml	Evidence-capture and diagnostic scenarios.

Related

• Workload Utility: the load generator Caraxes drives, and the meaning of the artifacts it writes.
• Cluster: partitions, placement, and replication in CamusDB.
• Configuration: the node settings a cluster spec writes.
• Distributed Transactions: the commit path a kill under load exercises.
• A dragon to attack our own database: the story behind Caraxes and the reliability work it supports.
